Product Details

The Inverex Veyron II Premium 2.5KW 24V MPPT Solar Inverter is a top-of-the-line product designed for efficient and cost-effective solar power usage. With its advanced MPPT technology and 24V capacity, it maximizes energy production and reduces electricity costs. Invest in this reliable and high-performing inverter for a greener and more sustainable future.

• 5 Year Warranty, 2 Year Product Warranty, 3 Year Service Warranty.
• Built-in WiFi for remote monitoring.
• Works without battery
• The wide PV input voltage range starts from 30VDC.
• User-friendly, LCD operation.
• Battery Equalization function to optimize battery performance and extended life cycle.
• Maximum solar charging current 100A
• Maximum MPPT input current 20A
• Built-in communication port for BMS
• Consuming 100% of your inverter output with your maximum PV array connection


  Description

  Model	Veryon II Premium  2500 Watt – 24V
  Rated Power	2500 VA/ 2500 Watt
  Voltage	230VAC
  Selectable Voltage Range	170 – 280 VAC(For Personal Computer) 90-280 VAC(For Home Appliances)
  Frequency Range	50Hz/60Hz (Auto Sensing)
  AC Voltage Regulation (Battery. Mode)	230 VAC ± 5%
  Surge Power	5000 VA
  Efficiency Peak	93%
  Transfer Time	10 ms (For Personal Computer) 20 ms (For Home Appliances)
  WaveForm	Pure Sine Wave
  Battery Voltage	24VDC
  Floating Charge Voltage	27 VDC
  Overcharge Protection	32 VDC
  Solar Charger Type	MPPT
  Maximum PV Array Open Circut Voltage	450 VDC
  Maximum PV Array Power	3000 Watt
  MPP Range @ Operating Voltage	30-400 VDC
  Maximum PV Input Current	20 Ampere
  Maximum Solar Charge  Current	100 Ampere
  Maximum AC Charge Current	80 Ampere
  Maximum Charge Current	100 Ampere
  Dimension D X W X H mm	114 x 308 x 438
  Net Weight	7.9 KG
  Communication Interface	RS 232/CAN/RS485/Wifi
  Humidity	5% ~ 85% (without condensation)
  Operating Temperature	-10° C to 50° C
  Storage Temperature	-15° C to 60° C
