PCB Mount Female Audio Connector DIP Stereo Headphone Jack
3.5mm Stereo Jack Socket Chassis with nut PCB Panel Mount Chassis adapter
Specifications:
- Size : 1.7 x 1.1 x 0.9cm / 0.67″ x 0.43″ x 0.35″(L*W*H);
- Color : Silver Tone, Black
- Jack Connection: Female
- Contact Resistance: =0.03O
- Insulation Resistance: =100MO
- Withstand Voltage: AC500V(50Hz)/min
- Temperature Range: -40~ 55
- Rated Load: DC 30V 0.5A
- Insertion and Extraction Force: 3~20N
- Lift: 5000 times
- 3.5mm DIP phone jack used for mobile phone,MP3/MP4 player, other electronical equipment.
Package includes:
- 1x PCB-mount Audio female socket
